LMQ3921 QSFP-DD DR4 Optical Transceiver
4x100G 1310nm 500m/2km
The LTA1328 QSFP28 Optical transceiver is intended for the service with single mode fiber in 103.125Gb/s high speed data communications and computing applications. It meets the requirements of QSFP28 MSA,CWDM4 MSA, operates from a 3.3V DC power supply and is of-fered in the commercial temperature range. The module has an aggregate link bandwidth in excess of 100Gb/s by multiplexing of 4 CWDM opti-cal lanes, each lane capable of transmitting 25.78125Gb/s over 2km on SMF optical fiber. It is fabricated with a rugged die cast metal housing and cage assembly. The device is Class I laser safety compliant and meets the EU Directive 2002/95/EC for RoHS compliance.
加入询单Part Number | Package | Interface | Reach | Temp | Fiber Type | Wavelength | Rate | Tx Output | Rx Input |
---|---|---|---|---|---|---|---|---|---|
LMQ3921-PC+ | QSFP-DD | MPO | 500m/2km | C | Single-mode | 1310nm | 4x100Gb/s | -2.9~4dBm(each lane) | -5.9~4dBm (each lane) |
• High performance computing interconnect
• Data Centers
• Cloud Networks
• 8 independent electrical input/output channels
• 4 independent parallel optical channels
• MPO optical connector
• Hot Pluggable
• 500m link on SMF single-mode Fiber
• Silicon photonics Technology
• QSFP-DD MSA Compliance
• Case Operating Temperature:
• Commercial: 0 to 70ºC
• RoHS II Compliance
