STB with GPON/EPON Access


The ONT&IPTV/OTT Fusion all-in-one is a converged intelligent network set-top box terminal launched by Hisense for the increasingly popular FTTH scenario. This series of products with both Home Gateway (HGU) and Intelligent Set Top Box (IPTV) capabilities will become the core terminal devices for smart homes. It adopts innovative design and PON access function; it adopts modular and universal design concept to realize the combination of different technical solutions. It can integrate rich and customized business.


GPON/EPON ONT Router combined with 4K UHD IPTV/OTT STB

IEEE 802.11b/g/n MIMO 2*2 2.4GHz

One Port 1000Base-T(GE) + One Port 100Base-T(FE)

Econet EN7526 SoC for ONT

Quad-core Amlogic S905L2 SoC for IPTV/OTT STB

Support HDMI 2.0

H.265 HEVC decoding up to 4K*2K@60fps

Android OS to provide ability to install APPs as requested

Support Dolby Digital and Dynamic HDR10, HDR10+, HLG

Support RTSP, RTP, RTCP, HLS streaming media protocol

Support DLNA Multi screen interactive protocol

Support 2.488Gbps downstream data rate and 1.244 Gbps upstream data rate

Providing one POTS port with VOIP, users can make or receive phone calls

Support 802.11 b/g/n standard WiFi access

Support IGMP v2/3, IPv4/6 Dual Stack

Support multiple internet modes, DHCP/PPPOE/Static IP/Bridge WAN

Support port forwarding and L3 routing

Support the ONT management and Control Interface OMCI and TR069 network management
